Φ4.8×76m Rotary Kiln

Technical Performance ofΦ4.8×76m Rotary Kiln:
1. Specification: φ4.8×76m rotary kiln
2. Output: 5000t/d dry process cement production line
3. Inclination: 4%
4. Rotating speed: main driving part: 0.35-4r/min; auxiliary driving part: 8.52r/h.
5. Amount of supports: 3
6. Sealing type: kiln head: sheet steel sealing; kiln end: air cylinder sealing
7. Cooling of kiln head: air cooling
8. Thrust roller type: hydraulic type with oil pump station
9. Driving mode: Single driving
10. Motor of main driving: ZSN4-400-092; power: 630kW; rotating speed:1500r/min; rated voltage: 440V
11. Main speed reducer: JH710C-SW305-40
12. Auxiliary motor: Y225M-4 IP44 45KW
13. Auxiliary speed reducer: JH220C-SV302-31.5.

Main Components ofΦ4.8×76m Rotary Kiln:
1. Cylinder part: the total weight of cylinder body is 368,000kg; its base plate is easy to replace; and its tyres are made of cast steel and of rectangular solid structure.
2. Driving device
3. Supporting device
4. Thrust roller oil pump station
5. Sealing equipment for kiln head and end.
6. Air cooling pipe
7. Particular tools for rotary kiln
8. Total weight of equipment: 854000kg

Established in 1994, Jiangsu Pengfei Group Co., Ltd is a professional manufacturer of Φ4.8×76m rotary kiln in China. Besides Φ4.8×76m rotary kiln, we also provide customers worldwide with oxidized pellet rotary kiln, bauxite rotary kiln, cement production line, cement grinding plant, industrial kiln and furnace, grinding equipment, crushing equipment, environmental protection equipment, cooling equipment, drying equipment, compound fertilizer equipment, packing machine, chemical equipment and electrical control system. With the certification of ISO9000 and CE, our products have been well received by customers from as many as 60 countries and districts such as Germany, Russia, Brazil, Egypt, Japan, South Korea, Bengal, Pakistan, Turkey, Vietnam, South Africa, Columbia, Bolivia, etc. If you're interested in our Φ4.8×76m rotary kiln, please contact us freely.
