Spray Granulation Dryer
Description of Spray Granulation Dryer:
This PZ type spray granulation dryer has integrated the spraying, granulating, and drying into one body. A series of new technologies have been used in the process of its manufacture, such as strengthened bricks, heat transfer, internal classification, internal material returning, internal crushing, and so on.
It has features of high productivity, easy operation, energy saving, simple process flow, etc.
Technical Parameters of PZ Series Spray Granulation Dryer
| Specification | Output (t/h) | Rotating speed of cylinder(r/min) | Cylinder slope (%) | Inlet temperature | Slurry temperature | Moisture of slurry | Motor power (kw) | Weight (t) |
| Φ3.0×12 | 100-150 | 5.0 | 1.76 | 350℃ | 110℃ | 25-30% | 55 | 71.0 |
| Φ3.0×13 | 100-150 | 5.0 | 1.76 | 350℃ | 110℃ | 25-30% | 55 | 75.3 |
| Φ4.0×12 | 150-200 | 4.1 | 1.5 | 350℃ | 110℃ | 25-30% | 110 | 105 |
| Φ4.0×14 | 150-200 | 4.1 | 1.5 | 350℃ | 110℃ | 25-30% | 130 | 109.8 |
| Φ3.0×12 | 200-300 | 4.1 | 1.5 | 450℃ | 110℃ | 25-30% | 160 | 151 |
| Φ3.0×12 | 200-300 | 4.1 | 1.5 | 450℃ | 110℃ | 25-30% | 185 | 160 |
| Φ3.0×12 | 400-500 | 4.1 | 1.5 | 450℃ | 110℃ | 25-30% | 220 | 184 |
| Φ3.0×12 | 400-500 | 4.1 | 1.5 | 450℃ | 110℃ | 25-30% | 250 | 196 |
| Φ3.0×12 | 500-600 | 4.1 | 1.5 | 650℃ | 115℃ | 25-30% | 280 | 255 |
| Φ3.0×12 | 500-600 | 4.1 | 1.5 | 650℃ | 115℃ | 25-30% | 315 | 265 |
Note:
1. The moisture of its products is no more than 1.5%.
2. 1-4mm particle size is more than 90%.
Established in 1994, Jiangsu Pengfei Group Co., Ltd is a professional manufacturer of spray granulation dryer in China. Besides spray granulation dryer, we also provide customers worldwide with rotary dryer, rotary cooler, cement production line, cement grinding plant, industrial kiln and furnace, grinding equipment, crushing equipment, environmental protection equipment, cooling equipment, drying equipment, compound fertilizer equipment, packing machine, chemical equipment and electrical control system. With the certification of ISO9000 and CE, our products have been well received by customers from as many as 60 countries and districts such as Germany, Russia, Brazil, Egypt, Japan, South Korea, Bengal, Pakistan, Turkey, Vietnam, South Africa, Columbia, Bolivia, etc. If you're interested in our spray granulation dryer, please contact us freely.
