Vibrating Feeder
Description of Vibrating Feeder:
This vibrating feeder is mainly used to feed bulk or particle materials evenly, regularly and continuously in various fields. When used in sand production line, it can continuously feed materials for crushing machines, and also carry out coarse screening for materials.
It is widely used in crushing work in industries like metallurgy field, coal or mining industry, mineral refining field, chemical industry, grinding sector, etc.
Features of Vibrating Feeder:
1. Stable vibration, reliable performance, and long service life
2. The vibrating force as well as the material quantity inside the feeder can be adjusted easily.
3. The vibrating motor, used as the driving source, has advantages of low noises, small energy consumption and stable performance.
Parameters of Vibrating Feeder:
| Model | Groove size (mm) | Max.feeding material size (mm) | Processing capacity (t/h) | Rotating speed of spindle (r/min) | Motor power (kw) | inclination angle of groove | Weight (excluding electric motor) (kg) | Overall dimensions (mm) |
| ZSW-300×70 | 3000×700 | ≤500 | 60-120 | 350-800 | 7.5 | 0 | 3225 | 3075×1450×1250 |
| ZSW-380×95 | 3800×950 | ≤500 | 100-160 | 350-800 | 11 | 0 | 4210 | 3882×1684×1340 |
| ZSW-490×100 | 4900×1000 | ≤500 | 120-200 | 350-800 | 15 | 0 | 5004 | 4957×1677×1365 |
| ZSW-360×110 | 3600×1100 | ≤500 | 100-160 | 350-800 | 11 | 0 | 4321 | 3700×1805×1195 |
| ZSW-490×110 | 4900×1100 | ≤580 | 200-300 | 350-800 | 15 | 0 | 6700 | 4957×1841×1365 |
| ZSW-590×130 | 5900×1300 | ≤700 | 300-400 | 750 | 22 | 5 | 7900 | 4957×1841×1365 |
| ZSW-600×110 | 6000×1100 | ≤600 | 400-500 | 350-800 | 22 | 0 | 8200 | 6000×1841×1365 |
Note: Parameters in the form is only for reference, and specific ones should be refer to the signed contract technology.
Established in 1994, Jiangsu Pengfei Group Co., Ltd is a professional manufacturer of vibrating feeder in China. Besides vibrating feeder, we also provide customers worldwide with chain bucket conveyor, apron feeder, cement production line, cement grinding plant, industrial kiln and furnace, grinding equipment, crushing equipment, environmental protection equipment, cooling equipment, drying equipment, compound fertilizer equipment, packing machine, chemical equipment and electrical control system. With the certification of ISO9000 and CE, our products have been well received by customers from as many as 60 countries and districts such as Germany, Russia, Brazil, Egypt, Japan, South Korea, Bengal, Pakistan, Turkey, Vietnam, South Africa, Columbia, Bolivia, etc. If you're interested in our vibrating feeder, please contact us freely.
